Description

Get ready to game away till you drop, for your mounting problems are over! We have a monitor arm for your 49" Samsung G9 monitor and other such ultra-curved, super ultrawide monitors. Available in desk mount (EDM-49G9D) or wall mount (EDM-49G9W), this arm has articulation too, it extends horizontally 23.6" and has a vertical lift of 11.5". But please bear in mind that the height adjustability of the arm reduces to around 4" when you mount it on the desk [11.5-(14.31/2) = 4.34", 14.31" being the G9's height without the stand.


Please note that the desk mount EDM-49G9D includes both desk clamp and grommet mount. The wall mounting EDM-49G9 come in polished aluminum and white color, while the desk mounting EDM-49G9 is also available in black (apart from white and polished aluminum). But please note that irrespective of the color of the arm you choose, the tilter is available only in white. The EDM-49G9 is sold with two tilters, one for the G9 monitor (comes in a separate box) and one for other ultrawide monitors (comes installed on the arm) that are up to 49" in size but not ultra-curved like the G9. This grants you the choice of mounting any 49" monitor on EDM-49G9. If you are buying this arm for your G9, please see the installation PDF in Downloads tab to find out how to replace the regular tilter with the tilter meant for the G9 monitor.

Replacement 1 - Ultrawide Monitor Arm for Samsung G9 EDM-49G9

Replacement 2 - Ultrawide Monitor Arm for Samsung G9 EDM-49G9

Technical Drawing

Technical drawing for Ergotron 45-475-026 HX Desk Mount Single Monitor Arm (polished aluminum)

Technical Specifications

LCD size Capacity Lift Tilt Pan Rotation VESA
Screen Capacity Lift Tilt Pan Rotation VESA
Up to 49"

28 - 42 lbs

12.7 - 19.1 kg

11.5"

29.2 cm

20° 180°360° MIS-D

Product Information

Description EDM-49G9 Monitor Arm
Includes
  • Arm

  • Extension

  • Monitor pivot

  • Desk clamp

  • Grommet mount

  • Monitor mounting hardware

Arm Folds back over the base into a compact retracted position; perfect for tucking under systems furniture storage shelves or cabinets in space constrained areas
Portrait/Landscape Rotation Portrait/landscape rotation with lockout
Cable Management Streamline cable management that routes cables under arm and within extension
Desk Clamp Desk clamp attaches to surface edge .4" to 2.4" (1 to 6 cm) thick
Grommet Mount Grommet mount attaches through surface holes
Clamp Base Clamp base ensures greater stability of display and arm
Rotation Monitor can be rotated 360° at connection point of arm and extension; rotation is restricted to 180° at connection point of extension and base
Mounting Standards VESA MIS-D, 75/100 (hole pattern = 100 x 100 mm & 75 x 75 mm), MIS-E (hole pattern = 200 x 100 mm), MIS-F (hole pattern = 200 x 200 mm ONLY). Optional VESA Bracket Adaptor Kit (97-759) can be ordered separately for MIS-F interface with hole pattern of 400 x 200 mm, 400 x 300 mm or 400 x 400 mm
Maximum Screen Size Maximum screen size determined by the monitor weight
Weight Capacity 20–42 lbs (9.1–19.1 kg)
Tilt Range 70° backward, 5° forward
Shipping Dimensions 12" x 19.2" x 7" (30.5 x 48.8 x 17.8 cm)
Shipping Weight 18.3 lbs (8.3 kg)
Warranty Ten (10) years

Benefits

  • G9 compatible - Works with 1000R curved monitors, like the Samsung 49" Odyssey G9
  • Neat look - Cables stay hidden under the arm and through the extension
  • Sturdy fit - Tilts +15/-5° to work or play comfortably
  • Protect your investment - Quality design securely supports large monitors
  • Reclaim space - Replaces bulky monitor bases, using no floor and desktop space
  • Simple adjustment - Enables precise screen positioning with patented Constant Force Technology

Product Options/Accessories

Model EDM-49G9D, EDM-49G9W
Manufacturer Ergotron
Part Number EDM-49G9D, EDM-49G9W
Color White
Monitor Size Up to 49"
Weight Capacity 28–42 lbs (12.7–19.1 kg)
Lift (29.2 cm) 11.5 in
Tilt 20 degree
Pan 180 degree
Rotation 360 degree
Mounting Pattern VESA MIS-D, 75/100 (hole pattern = 100 x 100 mm & 75 x 75 mm)
Maximum Extension Up to 24.5" (60 cm)
Warranty 10 years
