Peerless DST660 Tilt Wall Mount with Media Device Storage
Description
Designed to hold a display and media device, peerless DST660 is the ideal low profile solution for digital signage applications. An open wall plate for easy outlet access, various tilt options and portrait/ landscape ability add to its versatility. The universal design accommodates VESA patterns from 200 x 100 up to 400 x 400mm. For 600 x 400 and 800 x 400mm patterns, the ACC-V800X is available. In addition, component storage access is simple with the bottom disengaging design allowing the display to have a negative tilt that enables quick and easy computer maintenance without having to remove the display.
Helpful Hints: Adapter plate required for displays with Vesa patterns over 400x400
Technical Drawing
Specifications
| Color | Black |
| Finish | Powder Coat |
| Screen Size | 40" to 60" |
| VESA Pattern | 200 x 100 up to 400 x 400 |
| Weight Capacity | 125 lbs (57kg) |
| Distance from Wall | 2.83" (72mm) |
| Increlock Increments | 0, +3.5, +7 degree |
| Security Features | Security Hardware |
| Tilt | 0-10 degree |
| Package Contents |
|
| Product Dimensions | 18.50" x 17.16" x 2.83" (470 x 436 x 72mm) |
| Product Weight | 10.7 lbs (5kg) |
| Shipping Dimensions | 27.00" x 18.25" x 5.50" (686 x 464 x 140mm) |
| Shipping Weight | 15 lbs (7kg) |
| UPC Code | 735029282945 |
Features
Included security hardware deters tampering and loss
The media player can be removed from the bottom if replacement, repair or maintenance is necessary without having to remove the display
Accommodates media players up to 12" x 13" x 2.4"
Continuous tilt options from 0°-10° or fixed at 0°, 3.5° and 7°
Display can be mounted in portrait or landscape
Adapter plate compatible for VESA patterns larger than 400 x 400mm
Product Options/Accessories
| Model | DST660 |
| Manufacturer | Peerless Mounts |
| Part Number | DST660 |
| UPC | 735029282945 |
| Color | Black |
| Dimensions (W x H x D) | 18.50" x 17.16" x 2.83" (470 x 436 x 72mm) |
| Weight | 10.7 lbs (5kg) |
| Weight Capacity | 125 lbs (57kg) |
| Shipping Dimensions | 27.0" x 18.25" x 5.5" (686 x 464 x 140mm) |
| Shipping Weight | 15 lbs (7kg) |
| Monitor Size | 40" to 60" |
| Mounting Pattern | 200 x 100 up to 400 x 400mm |
| Tilt | Continuous from 0-10 degree or fixed at 0, 3.5 and 7 degree |
| Accomodates | Up to 12" x 13" x 2.4" |
| Warranty | Limited 5 year |
| Mounting Options | Wall |
| Finish | Powder Coat |
| Distance From Wall | 2.83" (72mm) |
