$165.00

Ergotron 60-604-003 WM Low Profile Wall Mount

Product ID 16042
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Installation
Side View
Rear View
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Ergotron 60-604-003 WM Low Profile Wall Mount
Installation
Side View
Rear View
Ergotron 60-604-003 WM Low Profile Wall Mount

Animation of Ergotron 60-604-003 WM Low Profile Wall Mount

Description

The WM’s wall-hugging design hangs your large flat panel display just over an inch from the wall for an extremely slim profile. Yet this TV wall mount costs about half that of competing models. Engineered to install in three easy steps, the WM is sturdy and stable.

Technical Drawing

Technical Drawing for Ergotron 60-604-003 WM Low Profile Wall Mount

Technical Specifications

LCD size Capacity Lift Tilt Pan Rotation VESA
Screen Capacity Lift Tilt Pan Rotation VESA

32" and larger

Up to 175 lbs

79.4 kg

- - - - MIS-D/E/F

Product Information

Part Number 60-604-003 (replacement for 60-578-003)
Description WM Low Profile Wall Mount (silver)
Includes
  • Wall plate

  • Two (2) display brackets

  • Hardware fastner kit

Mounting Holes Mounting holes must fit within spacing range below: horizontal = 100 mm (min.) to 600 mm (max.); vertical = 100 mm (min.) to 450 mm (max.)
Displays For displays with horizontal hole pattern of 601–800 mm, order WM, XL version (pt. # 60-602-003)
Mounting Options Wall plate attaches to vertical wall surfaces. Includes hardware for mounting to wood studs (16" centered studs) or concrete walls
WM, XL Version If mounting to wall using 24" centered studs, order WM, XL version (pt. # 60-602-003)
Premium Construction Composed of extruded aluminum and steel
Profile off the Wall 1.25" (32 mm)
UL Certified and Listed UL certified and listed to UL Standard 2442. This product has been tested to hold four times its maximum load capacity per UL standard (do NOT exceed listed weight capacity in actual use)
Shipping Dimensions 33.3"W x 10.4"H x 2.2"D (84.5 x 26 x 5.5 cm)
Shipping Weight 10 lbs (4.5 kg)
Warranty Five (5) years

Benefits

  • Installs in three simple steps

  • Extremely slim profile - just over an inch from the wall

  • Fits most screens greater than 32" up to 175 lbs (79 kg)

  • Protect your investment: Integrated security fasteners hold display in place and deter others from removing your display

  • Includes fasteners for mounting to wood studs or concrete

Model 60-604-003
Manufacturer Ergotron
Part Number 60-604-003
UPC 698833011661
Weight lb(s)
Color Silver
Monitor Size 32" and above
Weight Capacity Up to 175 lbs (79.4 kg)
Mounting Pattern Universal Display Attachment: Mounting holes must fit within spacing range below... Horizontal = 100 mm (min.) to 600 mm (max.) Vertical = 100 mm (min.) to 450 mm (max.)
Mounting Options Fixed Wall
Profile off the Wall 1.25" (32 mm)
Shipping Dimensions 33.3"W x 10.4"H x 2.2"D (84.5 x 26 x 5.5 cm)
Shipping Weight 10 lbs (4.5 kg)
Warranty Five (5) years
